Description
-
Bearing blocks with integrated servo mounts – solid servo mounting and direct linkages to the swash plate.
-
Carbon frames which are rigid and lightweight give a very clean look to the helicopter.
-
The servos can be easily removed from the helicopter frame.
-
Adjustable servo horns are included to provide an accurate linkages. (Only for JR servos)
-
6mm main shaft, 4mm tail shaft – strong and crash resistant.
-
Autorotation one way bearing integrated into the pinion gear, allowing a simple and leightweight main gear.
-
Helical tooth main gear results in a smooth drive train and low noise footprint.
-
The new belt drive system features a large front pulley, giving low drag drive to the tail rotor.
-
Originally-designed control lever – very simple with no free play – feels like a much larger helicopter.
-
FRP canopy neatly covers all the mechanics, giving a simple and smart appearance.
Specifications:
-
Length 663mm
-
Height 222mm
-
Width 135mm
-
Gross weight 820g or more
-
Main rotor diameter 731mm
-
Main blade length 325 – 350mm
-
Gear ratio 9.07 : 1 : 4.29
-
Main shaft diameter 6mm
-
Tail output shaft diameter 4mm
-
Tail rotor diameter 155.5mm
