Description
FEATURES
- Based on Simon-K firmware, further optimized to perfect performance
- Low-voltage protection, over-heat protection, and self-check functions
- Separate power supply for MCU and BEC, enhancing the ESC’s ability of eliminating magnetic interference
- Parameters of the ESC can be set via program card or transmitter
- Throttle range can be set to be compatible with different receivers
- Maximum speed: 210,000rpm for 2-pole; 70,000rpm for 6-pole; 35,000rpm for 12-pole
SPECIFICATIONS
| CONTINUOUS CURRENT: | 12A |
| BURST CURRENT: | 15A |
| LI-XX BATTERY: | 2-3 cells |
| DIMENSION: | L25 x W20 x H7mm |
| WEIGHT (w/ wires): | 9g |
| BEC MODE: | Linear |
| BEC OUTPUT: | 1A/5V |
| PROGRAMMABLE: | Yes |
