Description
KST X06H Wing Servo (0.8-1.8KG)
X06H is with the horizontal mount tabs. Perfect for installations where the servos are mounted laying flat, such as in wings and certain fuselages.
KST delivers once again with the X06 series competition servos for glider pilots and soaring enthusiasts who demand the best! The brand new X06 is super compact and ideal for F3K and F5K gliders. Featuring a slim 7mm wide casing crafted from 6061 Alloy and sporting the famous KST red midsection not only do these servos look fantastic but they also offer the competition winning performance you would expect from KST.
Features
Compact and Lightweight Design
Excellent Torque and Speed
Designed for High Performance RC Gliders
Excellent Heat Dissipation
Ultra-slim 7mm Body
Specification
Item: X06H Micro Servo
Voltage Range: DC6.0V
Rated Voltage: DC3.8V-8.4V
Torque: 0.8Kgf.cm@3.8V, 1.5Kgf.cm@6.0V, 1.8Kgf.cm@8.4V
Rated Torque: 4N.cm@6.0V
Stalling Current 0.58A@6.0V
Rated Current 0.22A@6.0V
Speed: 0.12sec/60°@3.8V, 0.08sec/60°@6.0V, 0.07sec/60°@8.4V
Rated Speed: 0.20sec/60°@6.0V
Default Travel Angle: ±60° = 120° Total
Operating Temperature Range: -10℃……+65℃
Soft Start: Programmable
Programmable: Yes
Case Material: Aluminum Alloy
Motor: Coreless DC Motor
Gear Set Material: Hardened Steel
Case Dimensions: 20mm*7mm*16.6mm±0.2mm
Weight: 6g±10%
Ball Bearing: 1BB
Package Including
1 * X06H V6.0 HV Servo
4 * Plastic Servo Horn
1 * Servo Horn Screw
4 * Mounting Screw
